Fever Scanning System & Thermal Scanning Solutions

Fever & Thermal Scanning Solutions

Solutions

Help Clients excite Attendees & create Opportunities for Growth

Audio & Visual

Monitor groups and individuals for increased body temperature via innovative fever scanning solutions. Integrate the right thermal detectors and tracking solutions with the software to improve the identification of individuals or groups with fever and track all participants for better contact tracing. Talk to Us

Seamless thermal scanning allows monitoring of larger groups in motion and to identify potential risk individuals to prevent contamination and infections

Talk to us

Solutions

Thermal Scanning Systems include hardware and software components to facilitate safe/thorough scanning and a smooth visitor experience. The Fever Scanning System usually includes the following components:

Isolation Camera System
Crowd Walk-through Scanning System
Warning & Notification System
Facial Detection
Self-check-in function
Video Incident Recording
Temperature Reporting
Contact Tracing System

Mounted Fever Scanning

Mounted Fever Scanning Solutions can automate a big part of the monitoring for larger venues or larger crowds of many days. The systems will perform a general total human traffic count, show the thermal image and create an alert upon fever detection. The key process is as follows:

1 or multiple mounted thermal cameras scan walk-through individuals for fever
Upon fever detection, an alarm can go off at a specific gate
An incident report is logged and automatically email / SMS notifications are triggered to key staff
Further information can be documented for the fever detection

The thermal fever screening cameras can perform high-precision VCA and trigger real-time warnings. The fast image processing and temperature exception alarm function allow calibrating for different background environments. The fever detection cameras can perform advanced facial detection to avoid scanning other hot objects (e.g. drink or technical devices). They can scan and detect up to 10 faces and thermal images at the same time. Get more detailed information on why you should buy our fever scanning system in our blog ‘Why Your Company Should Invest on Medical Scanners’

AI Thermal Scanner

Temperature Measuring Range: 30-45C (accuracy may decrease beyond this range)
Temperature Accuracy: +-0.5 C
Measuring Distance: 0.15-2m
Camera Resolution : 256×192
Camera FPS: 25 Hz
Camera Focal length: 3.2mm
Camera Field of View: 56″x42″
Camera F# : 1.1
Camera Size : 80x80x14.2 mm
Camera Weight: less than 77g
Camera IO: Mini USB
Camera Accuracy: +-0.5 C
Operating Temperature: 2-50C
Storage Temperature : -20C – 60C

Hand-held Solutions

Hand-held Fever Scanning Solutions are battery-powered and create flexible infrastructure for thermal scanning. Small-scale solutions work as dongles to smartphones or tablets. Dedicated fever hand-held scanners are usually more optimized for a specific purpose.
The small 3d laser scanners and dedicated software accommodate for distance analysis and compensation (as fever measurements reduce with distance) and common devices measure fever accurately up to 3 meters.

More sophisticated devices have a larger reach and provide 1280 x 960 pixels resolution with good thermal sensitivity. Many hand-held thermal scanners have HDMI interfaces for data transfer to an external screen, they can also be used in semi-stationary applications such as security checks. Warning: Some handheld or smartphone-specific accessories do not have sufficient measurement accuracy for fever detection (Example below). The details are visible in the technical specification.

Smartphone Thermal Scanner

Not sufficient for fever detection.

Material: metal
Color: black
Temperature range: -20C to 300C
Temperature Accuracy: ±3C or ±5% of reading
Temperature Resolution: 0.1C or 0.1C
Working band: 8-14μm
Horizontal viewing angle / vertical viewing angle: 43°±1°/ 43°±1°
Infrared image resolution: 32 * 32
Visible image resolution: 640 * 480
Image format: png
Video format: mp4
Frame rate: gHz
Focal length: fixed
Operation temperature range: 0C to 35C
Storage temperature range: -20C to 60C
Plug: USB Type-C
Power supply: power supply from external devices, such for Android phones
Item size: 60 * 30mm / 2.4 * 1.2in
Item weight: 19g / 0.7 ounce
Package size: 175 * 100 * 60mm / 6.9 * 3.9 * 2.4in
Package weight: 250g / 8.8 ounce
Detection Distance: within 2m

Fever-detection capable

Non-contact temperature measurement with 0.1s quick detection, Real-time temperature display with high and low-temperature automatic tracking, Accuracy ≤0.3 ° C after calibration (emissivity, temperature measurement point, temperature adjustable), Customizable automatic high-temperature alarm

Sensor: Uncooled focal plane
High and low-temperature alarm: Can be set for high and low temperature warning
Temperature measurement range 30°C 〜45°C
Temperature Resolution 0. 1°C
Temperature measurement response time W350ms
Temperature Accuracy ±0. 3°C （Best working distance: 1M）
Thermal imaging pixel 19200 (160*120)
Pixel size 12 |i m
Color: Iron Red, Rainbow, White Hot, Black Hot, Red Hot, Lava, High Contrast Rainbow
Infrared spectral bandwidth 8〜14卩m
Thermal imaging sensitivity 50mK
Frame rate 9Hz
Temperature display: ZF Center point temperature measurement and high-temperature tracking (default high-temperature tracking)
Image format BMP
Picture mode: Thermal imaging, digital camera (visible light), fusion
Temperature measurement point: In addition to the center point, 3 temperature measurement points can be added
Daylight visible: Yes
Visible light resolution 640*480
PC Analysis Software (PC) included
Real-time image transmission Yes (PC software real-time image projection screen)
Data communication Type-C USB
Display type 2.8″ TFT LCD
Display resolution 320*240
Battery Li-ion 3. 7V/5000mAh 26650 Single section
Image storage Micro SD card
Working temperature 0°C〜35°C

Contact Tracing

We support clients to smoothly document critical information to facilitate quick contact tracing in case of potential risk exposure. 1) Track movement across all doors, entry / pass-through points, and locations. 2) Provide specific contact lists for individuals with cross-contact. 3) Automated email / SMS follow-up with contact lists.

Fever Scanning System & Thermal Scanning Solutions FAQ

1. What should I Check When Buying a Fever Scanning Solution?

An ideal fever scanning solution consists of different components that make it convenient for the users. Our fever scanning system comes with a facial detection option, self-check-in option, temperature reporting, warning and notification system, etc. These are a few things that you need to check when bringing a fever scanning solution home

2. Which fever scanning solutions do you have to offer?

At Globibo, we have Mounted Fever Scanning Solutions and Hand-held Fever Scanning Solutions. Both these systems have unique features that make them suitable for your needs. You can learn more about them in detail above.

3. Why Do I Need a Thermal Scanning Solution?

When you have a thermal scanning solution, you can easily identify the individuals who can be a potential health risk in a crowd of countless people. It is a powerful way to prevent contamination and infections.
